FAN Specification
Size : 120x120x25 mm
Mounting hole spacing : 105x105 mm
Connector & pin-configuration : 4-pin PWM
Cable length : 40cm
Bearing : SSO2
Blade geometry : Heptaperf™
Frame technology : FocusedFlow™
Material : Fibre-glass reinforced polyamide
Ingress protection : IP52
Motor type : Three-phase
Rotational speed (+/- 10%) : 2000 RPM
Min. rotational speed (PWM, +/-20%) : 450 RPM
Airflow : 121,8 m³/h
Acoustical noise : 29,7 dB(A)
Static pressure : 3,94 mm H?O
Max. input power : 1,2 W
Max. input current : 0,1 A
Operating voltage : 12 V
MTTF : > 150.000 h
Scope of delivery
Fan
4 Fan Screws
