Socket Compability Support
Intel LGA : 2066/2011-v3/2011/1700/1200/1151/1150/1155
AMD : sTRX4/sTR4/AM5/AM4
Details
Weight LS320 : 1003g & LS520 : 1305g & LS720 : 1607g
Radiator Dimensions :
159 x 120 x 27 mm
282 x 120 x 27 mm
402 x 120 x 27 mm
Radiator Material : Aluminum
Tube length :
LS320 - 310mm
LS520 / LS720 - 410 mm
Pump Dimensions : 86×74×57 mm
Pump Speed : 3100 RPM±10%
Pump Noise : 19 dB(A)
Pump Connector : 3-pin
Pump Rated Voltage : 12 VDC
Pump Rated Current : 0.47 A
Pump Power Consumption : 5.64 W
Fan Dimensions : 120×120×25 mm
Fan Speed : 500~2250 RPM±10%
Fan Airflow : 85.85 CFM
Fan Air Pressure : 3.27 mmAq
Fan Noise : ? 32.9 dB(A)
Fan Connector : 4-pin PWM
Bearing Type : Fluid Dynamic Bearing
Fan Rated Voltage : 12 VDC
Fan Rated Current : 0.29 A
Fan Power Consumption : 3.48W
LED Type : Addressable RGB LED
LED Connector : 3-pin (+5V-D-G)
LED Rated Voltage : 5 VDC
LED Power Consumption : 2.2 W?PUMP?/ 1.8W (FAN x 1) 3.6 W?FAN x 2?5.4W (FAN x 3)
