Camera

Image Sensor 1/2.8" Progressive Scan CMOS

Shutter Speed Self-adaptive shutter

Lens 4mm@ F1.6, viewing angle: 49° (Vertical), 89° (Horizontal), 104° (Diagonal) 6mm@ F1.6, viewing angle: 28° (Vertical), 52° (Horizontal), 60° (Diagonal)

PT Angle Pan: 350°, Tilt: 80°

Minimum Illumination 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)

Lens Mount M12

Day & Night IR-cut filter with auto switch

DNR 3D DNR

WDR Digital WDR

Black & White Night 30m / 98ft

Video & Audio

Max Resolution 2304 × 1296

Frame Rate Max: 30fps; Self-Adaptive during network transmission

Video Compression H.265 / H.264

H.265 Type Main Profile

Video Bit Rate Ultra-HD; Hi-Def; Standard. Adaptive bit rate.

Audio Bit Rate Self-Adaptive

Network

Protocol EZVIZ Cloud Proprietary Protocol

Interface Protocol EZVIZ Cloud Proprietary Protocol

Wired Network RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

Functions

Smart Alarm AI-Powered Human Shape Detection

Auto Tracking Supports

Customized Alert Area Supports

Two-way Talk Supports

Preset Locations Supports

General Function Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark

Storage

Local Storage Supports MicroSD Card (Up to 512 GB)

Cloud Storage EZVIZ CloudPlay storage

General

Operating Conditions -30°C to 50°C ( -22 °F to 122 °F ) Humidity 95% or less (non-condensing)

IP Grade Weatherproof Design

Power Supply DC 12V/1A, Supports PoE power supply

Power Consumption MAX. 12W

Dimensions 100 × 136 × 140mm (3.94 × 5.35 × 5.51 inch)

Packaging Dimensions 140 × 140 × 192mm (5.51 × 5.51 × 7.56 inch)

Weight Net Weight: 525g With Package: 745g For EU Standard Version

In the box

[?] H8c PoE (2K) Camera

[?] Drill Template

[?] Screw Kit

[?] Waterproof Kit

[?] Regulatory Information

[?] Quick Start Guide

Certifications

Certifications CE / UL / RoHS / WEEE / REACH
