CPU : AMD Socket AM4, support for: AMD Ryzen 5000 Series/ Ryzen 5000 G-Series/ Ryzen 4000 G-Series and Ryzen 3000 and Ryzen 3000 G-Series Processors

Chipset : AMD B550

Memory : 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory

Onboard Graphics :

Integrated Graphics Processor with AMD Radeon Graphics support:

1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz

1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

Audio :

- Realtek Audio CODEC

- High Definition Audio

- 2/4/5.1/7.1-channel

LAN : Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)

Expansion Slots :

1 x PCI Express x16 slot, integrated in the CPU:

AMD Ryzen 5000 Series*/3000 Series Processors support PCIe 4.0 x16 mode

AMD Ryzen 5000 G-Series/4000 G-Series/3000 G-Series Processors support PCIe 3.0 x16 mode

1 x PCI Express x1 slot, integrated in the Chipset: Supporting PCIe 3.0 x1 mode

Storage Interface :

1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs:

AMD Ryzen 5000 Series/3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs

AMD Ryzen 5000 G-Series/4000 G-Series/3000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs

1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 SSDs:

Supporting PCIe 3.0 x2 SSDs

4 x SATA 6Gb/s connectors, integrated in the Chipset:

Support for RAID 0, RAID 1, and RAID 10

USB :

CPU : 4 x USB 3.2 Gen 1 ports on the back panel

Chipset :

2 x USB 3.2 Gen 1 ports available through the internal USB header

6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

Internal I/O Connectors :

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

1 x system fan header

2 x M.2 Socket 3 connectors

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB 3.2 Gen 1 header

1 x USB 2.0/1.1 header

1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)

1 x Clear CMOS jumper

Back Panel Connectors :

1 x PS/2 keyboard/mouse port

1 x DisplayPort

1 x HDMI port

4 x USB 3.2 Gen 1 ports

4 x USB 2.0/1.1 ports

1 x RJ-45 port

3 x audio jacks

I/O Controller : iTE I/O Controller Chip

BIOS :

- 1 x 128 Mbit flash

- Use of licensed AMI UEFI BIOS

- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Operating System :

- Support for Windows 11 64-bit

- Support for Windows 10 64-bit

Form Factor : Micro ATX Form Factor; 24.4cm x 24.4cm
