Specifications

Platform : Desktop
Product Line : AMD Ryzen 5 8000 G-Series Desktop Processors with Radeon Graphics
AMD PRO Technologies : No
Former Codename : "Phoenix"
Architecture : 2 x "Zen4", 4 x "Zen4c"
# of CPU Cores : 6
Multithreading (SMT) : Yes
# of Threads : 12
Max. Boost Clock : Up to 5.0GHz
Base Clock : 3.5GHz
L2 Cache : 6MB
L3 Cache : 16MB
Default TDP : 65W
Processor Technology for CPU Cores : TSMC 4nm FinFET
CPU Compute Die (CCD) Size : 137mm
Package Die Count : 1
CPU Socket : AM5
CPU Boost Technology : Precision Boost 2
Instruction Set : x86-64
Supported Extensions : AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Max. Operating Temperature (Tjmax) : 95C

OS Support
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit

Connectivity
Native USB 4 (40Gbps) Ports : 2
Native USB 3.2 Gen 2 (10Gbps) Ports : 2
Native USB 2.0 (480Mbps) Ports : 1
PCI Express Version : PCIe 4.0
Native PCIe Lanes (Total/Usable) : 14 / 10
NVMe Support : Boot, RAID0, RAID1
System Memory Type : DDR5

Graphics Capabilities
Integrated Graphics : Yes
Graphics Model : AMD Radeon 740M
Graphics Core Count : 4
Graphics Frequency : 2800 MHz
DirectX Version : 12
DisplayPort Version : 2.1
HDMI Version : 2.1
HDCP Version Supported : 2.3
USB Type-C DisplayPort Alternate Mode : Yes
Multi-Monitor Support : Yes
Max Displays : 4
AMD FreeSync : Yes
Wireless Display : Miracast

Limited Warranty 3-Year
