Supports 10th Gen & 11th Gen Intel Core Processors (LGA1200)
4 Power Phase Design
Supports DDR4 3200 MHz*
Intel® H470 Chipset
1 PCIe 4.0 x16, 1 PCIe 3.0 x1
Graphics Output Options: 2 HDMI
Realtek ALC897 7.1 CH HD Audio Codec
4 SATA3, 1 Ultra M.2 (PCIe Gen3 x4 & SATA3)
6 USB 3.2 Gen1 (4 Rear, 2 Front),
6 USB 2.0 (2 Rear, 4 Front)
Realtek Gigabit LAN
Supports ASRock Auto Driver Installer

CPU Supports 10th Gen & 11th Gen Intel Core Processors
Socket : LGA 1200
Chipset : Intel® H470
Power : 4 Power Phase Design
Memory : 2 x DDR4 DIMM Slots
- Supports DDR4 3200 / 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory*
- Supports ECC UDIMM memory modules (operate in non-ECC mode)
- Max. capacity of system memory: 64GB**
- Supports Intel® Extreme Memory Profile (XMP) 2.0

Expansion Slots :
1 PCIe 4.0 x16
1 PCIe 3.0 x1

Graphics : Intel UHD Graphics Built in Visuals and the VGA outputs can be supported onlywith processors which are GPU integrated

Graphics output : 2 HDMI

Storage :
4 x SATA3
1 x Ultra M.2 (PCIe Gen3x4 & SATA 3)

USB :
6 x USB 3.2 Gen1 (4 Rear, 2 Front)
6 x USB 2.0 (2 Rear, 4 Front)

Audio 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
LAN : Realtek Gigabit LAN

Form Factor : Micro ATX

Warranty 3 years by Asrock
